Analog Volt Meter

This SQ Series analog AC voltmeter is a reliable panel-mounted moving-iron meter, designed for direct voltage monitoring in industrial distribution panels, switchgears, and control cabinets.
It provides clear, intuitive readings for AC voltage. With Class 1.5 accuracy, it delivers stable and precise measurements for routine power monitoring.
Built with a durable black housing, this voltmeter is easy to install in standard panel cutouts. Operating reliably at -20°C to +50°C, it is ideal for indoor, non-corrosive environments in factories, buildings, and commercial power systems.

• Class 1.5 Accuracy
• Clear Analog Display
• Durable Moving-Iron Design
• Wide Operating Temperature

This SQ series analog voltage meter operates reliably in industrial and commercial environments, including control panels, distribution boards, and power monitoring cabinets.
Designed for -20°C to +50°C and up to 85% non-condensing humidity, it delivers stable performance in indoor and ventilated outdoor settings. With vibration-resistant construction, it suits manufacturing plants, building electrical systems, and renewable energy setups, offering clear visual readings for direct connection in standard 50/60Hz AC circuits.

When choosing an analog voltage meter for your electrical system, the SQ series analog voltmeter stands out as a reliable, cost-effective choice for industrial and commercial applications.

Unlike digital meters that rely on power and displays prone to failure, this analog unit provides instant, continuous visual voltage readings, letting operators spot overloads and fluctuations at a glance-no complex setup or calibration required.

With a proven 1.5 accuracy class, compatibility with standard 50/60Hz AC circuits, and a rugged, vibration-resistant build, it delivers stable performance in control panels, distribution boards, and manufacturing environments. Simple to install, low-maintenance, and immune to minor electromagnetic interference, it ensures long-term dependability for your power monitoring needs.

1. Installation

• Power off the circuit completely before installation to ensure safe operation.
• Confirm the voltmeter's measuring range, voltage level and accuracy class match your system requirements.
• Cut a standard panel opening according to the model (48×48mm / 72×72mm / 96×96mm), insert the meter and fix it firmly with mounting clips.
• Mount the meter vertically, away from strong magnetic fields, heat sources and heavy vibration areas.
• Connect the meter terminals to the measured circuit correctly, following polarity marks and wiring diagrams.

2. Operation

• Before power-on, check that all wiring is secure and the pointer points to zero. If not, adjust the zero screw on the front slightly.
• Switch on the power; the pointer will immediately indicate the real-time voltage value.
• Read the scale directly according to the selected voltage range for accurate measurement.
• Monitor the pointer continuously to detect abnormal voltage fluctuations or overload conditions.
• Do not open the meter case while powered on; avoid collision or strong vibration during use.

3. Maintenance

• Regularly inspect the appearance, dial and housing for damage, dust or dirt.
• Clean the surface with a dry soft cloth; do not use corrosive or chemical cleaners.
• Check terminal connections periodically to keep them tight and free of oxidation.
• Re-calibrate the zero position if the pointer drifts during long-term use.
• Store the meter in a dry, ventilated environment away from moisture and direct sunlight.
